Authorisation
|
RCM Mark
c UL us - Listed (OL)
|
|
CE mark (see declaration of conformity)
|
to EU directive for EMC
in accordance with EU RoHS directive
|
|
KC mark
|
KC-EMV
|
|
Materials note
|
Conforms to RoHS
|
|
Measured variable
|
Flow rate
Temperature
|
|
Direction of flow
|
Unidirectional P1 -> P2
|
|
Measurement method
|
Flow: vortex
Temperature: PT1000
|
|
Operating pressure
|
0 ... 12 bar
|
|
Note on operating pressure
|
Max. 12 bar at 40°C
Max. 6 bar at 100°C
|
|
Operating medium
|
Fluid media
Water
Neutral fluids
|
|
Note on operating and pilot medium
|
It must be ensured that the operating medium is compatible with the materials with which it is in contact.
|
|
Medium temperature
|
0 ... 90 °C
|
|
Ambient temperature
|
0 ... 50 °C
|
|
Nominal temperature
|
23 °C
|
|
Accuracy of flow rate
|
±2% FS for flow rate <= 50% FS
±3% of measured value for flow rate >= 50% FS
|
|
Accuracy of temperature in ± °C
|
2 °C
|
|
Repetition accuracy of flow rate value
|
< ±0.5% FS for flow rate <= 50% FS
< ±1% of measured value for flow rate >= 50% FS
|
|
Temperature co-efficient margin in ± %FS/K
|
typ. ±0,05%FS/K
|
|
Switch output
|
2 x PNP or 2 x NPN switchable
|
|
Switching function
|
Window comparator
Threshold value comparator Freely programmable
|
|
Switching element function
|
N/C or N/O contact, switchable
|
|
Max. output current
|
100 mA
|
|
Analogue output
|
0 - 10 V
4 - 20 mA
1 - 5 V
|
|
Max. load resistance, current output
|
500 Ohm
|
|
Min. load resistance, voltage output
|
15 kOhm
|
|
Short circuit strength
|
Yes
|
|
Overload withstand capability
|
Available
|
|
Protocol
|
IO-Link
|
|
IO-Link, protocol
|
Device V 1.1
|
