Authorisation
|
RCM Mark
c UL us - Listed (OL)
|
|
CE mark (see declaration of conformity)
|
to EU directive for EMC
|
|
Materials note
|
Contains PWIS substances Conforms to RoHS
|
|
Measured variable
|
Relative pressure
|
|
Measurement method
|
Thin metal film pressure sensor
|
|
Pressure measuring range, initial value
|
0 bar
|
|
Pressure measuring range, final value
|
50 bar
|
|
Overload range
|
100 bar
|
|
Operating medium
|
Compressed air in accordance with ISO8573-1:2010 [-:-:-]
Gaseous media
Fluid media
|
|
Medium temperature
|
0 ... 80 °C
|
|
Ambient temperature
|
0 ... 80 °C
|
|
Accuracy, FS
|
1 %FS
|
|
Repetition accuracy in ± %FS
|
0.1 %FS
|
|
Analogue output
|
4 - 20 mA
|
|
Linearity error in ± %FS
|
0.5 %FS
|
|
Short circuit strength
|
Yes
|
|
Operating voltage range DC
|
8 ... 30 V
|
|
Polarity protected
|
for operating voltage
|
|
Electrical connection
|
Plug
Round design
to EN 60947-5-2
M12x1
4-pin
|
|
Material connector housing
|
PA
|
|
Mounting type
|
Optional
with internal (female) thread with accessories
|
|
Assembly position
|
Any
|
|
Pneumatic connection
|
G1/4
|
|
Product weight
|
80 g
|
|
Material housing
|
PA
VMQ (silicon)
High alloy steel, non-corrosive
|
|
Materials in contact with media
|
High alloy steel, non-corrosive
|
|
Protection class
|
IP67
|
|
Corrosion resistance classification CRC
|
4 - Very high corrosion stress
|
